Chiranjiv Steel Centre is a leading manufacturer, supplier, stockist, and exporter of Carbon SA 516 Grade 60 NACE Steel Plates. Our focus on quality and innovation ensures that we provide top-notch products to our customers worldwide. These plates are well-known for being reliable and versatile, making them ideal for a wide range of industrial applications. The SA516 grade is a popular choice for manufacturing industrial pipe fittings due to its established reputation as a high-quality carbon steel grade. In addition, our alloy steel plates are specifically designed for pressure vessels that operate in lower-temperature environments, providing unmatched performance.
Our plates are extremely durable and versatile, making them essential in tough industrial settings. The varied tensile strengths of the alloy allow for smooth operations in a wide range of industries. At Chiranjiv Steel Centre, we add alloying elements to give our plates special properties. The plates are known for their ability to resist corrosion, such as pitting and crevice corrosion, due to their carbon content and other alloying elements.
Our plates have outstanding flexibility, long-lasting strength, and steadfast stability in high temperatures, guaranteeing top-notch performance and durability in important uses. Before we send out our SA 516 GR.70N WITH NACE + HIC BOILER PLATES, we conduct thorough testing, which includes hardness, hydrostatic, ultrasonic, positive material identification, as well as micro and macro tests. This process guarantees that our products meet high-quality standards and that our customers are completely satisfied.
Here at Chiranjiv Steel Centre, we tailor the packaging to fit the specific requirements of our clients, guaranteeing secure transportation and timely delivery. Our plates are crafted to surpass client standards, providing a variety of choices for surface texture, end design, measurements, forms, and proportions.
At Chiranjiv Steel Centre, we make sure our steel alloy plates always meet or exceed industry standards, both on a national and international level. Trust us to provide top-notch Carbon SA 516 Grade 60 NACE Steel Plates that will enhance your industrial operations.
| Grade | ASME SA 516 GR.60N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for Boilers and Pressure Vessels Application. |
| Process of Manufacturing | Hot-Rolled (HR) |
| British Standard | European Norm | ASTM/ASME | DIN |
|---|---|---|---|
| BS1501-161-430A | EN10028 P265GH | A/SA516 - Grade 60 | DIN 17155 HII |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
|---|---|---|---|
| 415-550 MPa | 250 MPa | 21 | 25 |
