Chiranjiv Steel Centre stands tall among the distinguished Manufacturers, Suppliers, Stockists, and Exporters of premium-grade Carbon SA 516 Grade 65 NACE Steel Plates, including plates crafted in various alloy forms and types. With an illustrious presence in the competitive market for years, we take pride in being the foremost suppliers and prominent manufacturers, wholesalers, traders, and exporters of the sought-after SA 516 GR.65N NACE MR 0103/0175 PLATES.
Our plates, available in diverse alloy types, boast enhancing qualities suitable for a wide range of temperatures, from low to high or high to low. We offer a plethora of options including different designations, shapes, thicknesses, sizes, specifications, standards, dimensions, grades, ranges, and designs to cater to varied requirements.
However, amidst our wide array of offerings, ASME SA 516 GR 65N HIC NACE MR 0103/0175 BOILER PLATES reign supreme as the most demanded product in both domestic and global markets. These carbon steel plates are engineered for lower and moderate temperature services, fortified with silicon, sulphur, phosphorus, and manganese to ensure superior resistance and mechanical properties.
They exhibit commendable resistance to corrosion, pitting and crevice corrosion, oxidation, abrasions, chloride stress, cracking corrosion, and more. Noteworthy attributes include higher tensile strength, easy fabrication, installation, and welding, along with good formability, ductility, hardness, toughness, and suitability for elevated temperature conditions.
The application spectrum of these plates spans across various industries including condensers, pulp and paper, petrochemicals, chemicals, gas processing, oil drilling, offshore operations, boiler equipment, surgical equipment, chemical applications, seawater environments, marine industries, and shipbuilding.
At Chiranjiv Steel Centre, we subject our products to rigorous testing including macro and micro tests, hardness tests, flattening and flaring tests, PMI tests, intergranular corrosion tests, destructive and non-destructive tests, ultrasonic tests, toughness tests, strength tests, chemical tests, mechanical tests, and more to ensure impeccable quality.
| Grade | ASME SA 516 GR.60N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for Boilers and Pressure Vessels Application. |
| Process of Manufacturing | Hot-Rolled (HR) |
| British Standard | European Norm | ASTM/ASME | DIN |
|---|---|---|---|
| BS1501-161-430A | EN10028 P265GH | A/SA516 - Grade 60 | DIN 17155 HII |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
|---|---|---|---|
| 415-550 MPa | 250 MPa | 21 | 25 |
