Chiranjiv Steel Centre stands as a premier entity among Manufacturers, Suppliers, Stockists, and Exporters, specializing in Carbon SA 516 Grade 65 Steel Plates. These plates boast a meticulously crafted composition, encompassing essential elements like manganese, sulfur, silicon, aluminum, chromium, phosphorous, carbon, copper, nickel, molybdenum, niobium, titanium, and vanadium. Each plate is tailored to exhibit distinct mechanical properties, including yield strength, tensile strength, elongation, and thickness, ensuring optimal performance across various applications.
Diversifying its offerings, Chiranjiv Steel Centre provides SA 516 GR 65 Boiler Quality Steel plates in an array of types, ranging from polished to hot-rolled and cold-rolled variants. Surface options abound, featuring finishes like hairline, checkered, sandblast, etching, mirror, and embossed, among others, catering to diverse aesthetic and functional requirements.
The versatility of Grade 65 Plates extends across industries, finding utility in seawater applications, pharmaceuticals, chemical equipment, heat exchangers, paper & pulp, oil drilling, gas processing, and food processing. Notably, these plates are indispensable in kitchens, sanitation, and food-related endeavors, underscoring their paramount importance in maintaining hygiene and safety standards.
Chiranjiv Steel Centre's commitment to quality is evident in its meticulous testing procedures post-production. From chemical and mechanical tests to hardness assessment, intergranular corrosion evaluation, and ultrasonic scrutiny, each plate undergoes a comprehensive inspection regimen to ensure adherence to stringent standards. This dedication extends to specialized tests like flaring, pitting resistance, flattening, radiography, positive material identification, and hydrostatic testing, reinforcing the reliability and durability of every SA 516 GR 65 Plate.
In addition to its focus on quality and performance, Chiranjiv Steel Centre prioritizes customer satisfaction, offering an extensive range of household stainless steel, high nickel alloys, and carbon steel products. With a steadfast commitment to excellence, Chiranjiv Steel Centre continues to be a trusted partner for industries worldwide, providing superior solutions for pressure vessels, columns, palm oil processing, food refining, architectural applications, and more.
| Grade | ASME SA 516 GR.60 Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for Boilers and Pressure Vessels Application. |
| Process of Manufacturing | Hot-Rolled (HR) |
| British Standard | European Norm | ASTM/ASME | DIN |
|---|---|---|---|
| BS1501-161-430A | EN10028 P265GH | A/SA516 - Grade 60 | DIN 17155 HII |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0.18 | 0.4 | 0.95/1.50 | 0.015 | 0.008 | 0.02 (Min) | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Yield strength (ksi) | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
|---|---|---|---|
| 485-620 (70-90) | 260 (38) | 17 | 21 |
